Hydrolysis resistance PSU Natural ROD for electronics industry

Availability:

Quantity:




Inquire Add to Basket

JUTAIPSU®NA, PSU extruded natural rod is a transparent yellow, amorphous thermoplastic material characterized by high rigidity even at elevated temperatures, good resistance to high-energy radiation, and excellent hydrolysis resistance. The long-term service temperature range for PSU rods is -50°C to 160°C, with a short-term maximum use temperature of 180°C. Its physical properties remain almost unchanged across a wide range of temperatures and electrical frequencies.

Typical application areas for PSU rods include the electrical and electronics industry, medical technology, and household appliances. PSU rods are highly suitable for blank processing, precision grinding, and CNC turning.

PSU Natural ROD PSU Natural ROD for electronics industry Hydrolysis resistance PSU Natural ROD High rigidity PSU Natural ROD Low smoke generation PSU Natural ROD High tensile strength PSU Natural ROD Electrical insulation PSU Natural ROD

RELATED PRODUCTS

Outstanding radiation resistance PSU Natural Sheet

High-end electric stable heat resistance PEEK SHEET

Low Coefficient of Friction Polyether Ether Ketone Black Tube

PEEK SHEET, Chemical Resistance Polyether Ether Ketone Sheet

High-performance engineering1mm Polyether Ether Ketone Sheet

Performance	Test Method	Unit	PSU Natural
Color	Eye	/	Translucent amber
Density	ISO 1183-1	g/cm³	1.24
Tensile Strength	ISO 527-2	MPa	≥75
Tensile Modulus	ISO 527-2	GPa	≥2.5
Elongation At break	ISO 527-2	%	≥15
Charpy Impact Strength (Notched)	ISO 179	kJ/m²	≥4.5
Flexural Strength	ISO 178	MPa	≥100
Flexural Modulus	ISO 178	GPa	≥2.5
Ball Hardness	ISO 2039-2	MPa	≥130
Glass Transition Temperature	ISO 11357-2	℃	187
Coefficient of Linear Thermal Expansion	ISO 11359-2	10-6/K	≤60
Long-term ServiceTemperature	IEC216	℃	160
Heat Deflection Temperature	ISO 75-1/2	℃	≥170
Water Absorption(23℃、50%RH、Saturation)	ISO 62	%	≤0.3
Flame Resistance(3mm)	UL 94	/	V-2
Volume Resistivity	IEC 62631-3-1	Q-cm	≥10^14
Dielectric Strength	IEC 60243-1	kV/mm	≥37
Dielectric Constant(1MHz)	IEC 62631-2-1	/	3.1
Dielectric Loss(1MHz)	IEC62631-2-1	/	6.4*10^-3

Performance	Test Method	Unit	PSU Natural
Color	Eye	/	Translucent amber
Density	ISO 1183-1	g/cm³	1.24
Tensile Strength	ISO 527-2	MPa	≥75
Tensile Modulus	ISO 527-2	GPa	≥2.5
Elongation At break	ISO 527-2	%	≥15
Charpy Impact Strength (Notched)	ISO 179	kJ/m²	≥4.5
Flexural Strength	ISO 178	MPa	≥100
Flexural Modulus	ISO 178	GPa	≥2.5
Ball Hardness	ISO 2039-2	MPa	≥130
Glass Transition Temperature	ISO 11357-2	℃	187
Coefficient of Linear Thermal Expansion	ISO 11359-2	10-6/K	≤60
Long-term ServiceTemperature	IEC216	℃	160
Heat Deflection Temperature	ISO 75-1/2	℃	≥170
Water Absorption(23℃、50%RH、Saturation)	ISO 62	%	≤0.3
Flame Resistance(3mm)	UL 94	/	V-2
Volume Resistivity	IEC 62631-3-1	Q-cm	≥10^14
Dielectric Strength	IEC 60243-1	kV/mm	≥37
Dielectric Constant(1MHz)	IEC 62631-2-1	/	3.1
Dielectric Loss(1MHz)	IEC62631-2-1	/	6.4*10^-3

PSU Natural Rod Specification
Diameter x Length ( mm)	Unit Weight (Kg)	Diameter x Length ( mm)	Unit Weight (Kg)	Diameter x Length ( mm)	Unit Weight (Kg)
4 x 1000	0.024	4 x 2000	0.048	4 x 3000	0.073
5 x 1000	0.036	5 x 2000	0.072	5 x 3000	0.108
6 x 1000	0.05	6 x 2000	0.10	6 x 3000	0.15
8 x 1000	0.08	8 x 2000	0.16	8 x 3000	0.23
10 x 1000	0.12	10 x 2000	0.23	10 x 3000	0.35
12 x 1000	0.16	12 x 2000	0.33	12 x 3000	0.49
15 x 1000	0.24	15 x 2000	0.48	15 x 3000	0.73
20 x 1000	0.43	20 x 2000	0.85	20 x 3000	1.28
25 x 1000	0.66	25 x 2000	1.32	25 x 3000	1.98
30 x 1000	0.94	30 x 2000	1.88	30 x 3000	2.82
35 x 1000	1.27	35 x 2000	2.54	35 x 3000	3.81
40 x 1000	1.65	40 x 2000	3.29	40 x 3000	4.94
45 x 1000	2.08	45 x 2000	4.17	45 x 3000	6.25
50 x 1000	2.64	50 x 2000	5.29	50 x 3000	7.93
55 x 1000	3.18	55 x 2000	6.36	55 x 3000	9.53
60 x 1000	3.66	60 x 2000	7.32	60 x 3000	10.99
65 x 1000	4.33	65 x 2000	8.66	65 x 3000	12.99
70 x 1000	5.12	70 x 2000	10.23	70 x 3000	15.35
75 x 1000	5.89	75 x 2000	11.78	75 x 3000	17.67
80 x 1000	6.74	80 x 2000	13.49	80 x 3000	20.23
90 x 1000	8.47	90 x 2000	16.93	90 x 3000	25.40
100 x 1000	10.55	100 x 2000	21.10	100 x 3000	31.65
110 x 1000	12.50	110 x 2000	24.99	110 x 3000	37.49
120 x 1000	14.81	120 x 2000	29.62	120 x 3000	44.44
130 x 1000	17.45	130 x 2000	34.89	130 x 3000	52.34
140 x 1000	20.16	140 x 2000	40.32	140 x 3000	60.48
150 x 1000	23.07	150 x 2000	46.13	150 x 3000	69.20
160 x 1000	26.32	160 x 2000	52.64	160 x 3000	78.96
170 x 1000	29.63	170 x 2000	59.27	170 x 3000	88.90
180 x 1000	33.13	180 x 2000	66.26	180 x 3000	99.39
190 x 1000	36.84	190 x 2000	73.68	190 x 3000	110.52
200 x 1000	40.74	200 x 2000	81.47	200 x 3000	122.21

PSU Natural Rod Specification
Diameter x Length ( mm)	Unit Weight (Kg)	Diameter x Length ( mm)	Unit Weight (Kg)	Diameter x Length ( mm)	Unit Weight (Kg)
4 x 1000	0.024	4 x 2000	0.048	4 x 3000	0.073
5 x 1000	0.036	5 x 2000	0.072	5 x 3000	0.108
6 x 1000	0.05	6 x 2000	0.10	6 x 3000	0.15
8 x 1000	0.08	8 x 2000	0.16	8 x 3000	0.23
10 x 1000	0.12	10 x 2000	0.23	10 x 3000	0.35
12 x 1000	0.16	12 x 2000	0.33	12 x 3000	0.49
15 x 1000	0.24	15 x 2000	0.48	15 x 3000	0.73
20 x 1000	0.43	20 x 2000	0.85	20 x 3000	1.28
25 x 1000	0.66	25 x 2000	1.32	25 x 3000	1.98
30 x 1000	0.94	30 x 2000	1.88	30 x 3000	2.82
35 x 1000	1.27	35 x 2000	2.54	35 x 3000	3.81
40 x 1000	1.65	40 x 2000	3.29	40 x 3000	4.94
45 x 1000	2.08	45 x 2000	4.17	45 x 3000	6.25
50 x 1000	2.64	50 x 2000	5.29	50 x 3000	7.93
55 x 1000	3.18	55 x 2000	6.36	55 x 3000	9.53
60 x 1000	3.66	60 x 2000	7.32	60 x 3000	10.99
65 x 1000	4.33	65 x 2000	8.66	65 x 3000	12.99
70 x 1000	5.12	70 x 2000	10.23	70 x 3000	15.35
75 x 1000	5.89	75 x 2000	11.78	75 x 3000	17.67
80 x 1000	6.74	80 x 2000	13.49	80 x 3000	20.23
90 x 1000	8.47	90 x 2000	16.93	90 x 3000	25.40
100 x 1000	10.55	100 x 2000	21.10	100 x 3000	31.65
110 x 1000	12.50	110 x 2000	24.99	110 x 3000	37.49
120 x 1000	14.81	120 x 2000	29.62	120 x 3000	44.44
130 x 1000	17.45	130 x 2000	34.89	130 x 3000	52.34
140 x 1000	20.16	140 x 2000	40.32	140 x 3000	60.48
150 x 1000	23.07	150 x 2000	46.13	150 x 3000	69.20
160 x 1000	26.32	160 x 2000	52.64	160 x 3000	78.96
170 x 1000	29.63	170 x 2000	59.27	170 x 3000	88.90
180 x 1000	33.13	180 x 2000	66.26	180 x 3000	99.39
190 x 1000	36.84	190 x 2000	73.68	190 x 3000	110.52
200 x 1000	40.74	200 x 2000	81.47	200 x 3000	122.21
