Low moisture absorption Polyether Ether Ketone GF30 SHEET

Availability:

Quantity:




Inquire Add to Basket

JUTAIPEEK®GF30 SHEET, PEEK GF30 SHEET, PEEK sheet profile contains 30% short-cut glass fibers, which significantly reduce the expansion rate of PEEK and increase its flexural modulus. This grade is well-suited for structural applications that require enhanced strength, stiffness, or stability, especially in temperatures exceeding 150°C. The color of glass-filled PEEK is light brown or brownish.

Polyether Ether Ketone GF30 SHEET light brown Polyether Ether Ketone GF30 SHEET brownish Polyether Ether Ketone GF30 SHEET Low moisture absorption Polyether Ether Ketone GF30 SHEET High-temperature resistance Polyether Ether Ketone GF30 SHEET chemical resistance Polyether Ether Ketone GF30 SHEET

RELATED PRODUCTS

High Rigidity PEEK ESD 10^6-10^9 Sheet for Electronics industry

High mechanical strength stable PPS GF40 Sheet

Connectors and IC sockets Polyphenylene Sulfide GF40 ROD

Flame-retardant Polyetherimide Sheet for Aerospace and Automotive

PEI GF30 for Resistance to high stress environments

Performance	Test Method	Unit	PEEK Natural
Color	beige	/	Beige
Density	ISO1183-1	g/cm³	1.3
Tensile Strength	ISO 527-2	MPa	≥100
Tensile Modulus	ISO 527-2	GPa	≥4.0
Elongation At Break	ISO 527-2	%	≥25
Charpy Impact Strength (Notched)	ISO 179	kJ/m²	≥4.0
FlexuralStrength	ISO 178	MPa	≥150
Flexural Modulus	ISO 178	GPa	≥3.5
Rockwell Hardness	ISO 2039-2	M	≥100
Shore D Hardness	ISO 868	Shore D	≥85
Coefficient of Linear Thermal Expansion	ISO 11359-2	10-6/K	≤65
Long-term Service Temperature	UL 746B	℃	250
Heat Deflection Temperature	ISO 75-2	℃	≥150
WaterAbsorption (23℃、Water、24h)	ISO 62	%	≤0.1
Flammability Resistance (1.6mm)	UL94	/	V-0
Volume Resistivity	IEC 62631-3-1	Q ·cm	1014-1016
Dielectric Strength	IEC 60243-1	kV/mm	≥15
DielectricConstant(1MHz)	IEC 62631-2-1	/	3.4
Dielectric Loss(1MHz)	IEC 62631-2-1	/	0.086

Performance	Test Method	Unit	PEEK Natural
Color	beige	/	Beige
Density	ISO1183-1	g/cm³	1.3
Tensile Strength	ISO 527-2	MPa	≥100
Tensile Modulus	ISO 527-2	GPa	≥4.0
Elongation At Break	ISO 527-2	%	≥25
Charpy Impact Strength (Notched)	ISO 179	kJ/m²	≥4.0
FlexuralStrength	ISO 178	MPa	≥150
Flexural Modulus	ISO 178	GPa	≥3.5
Rockwell Hardness	ISO 2039-2	M	≥100
Shore D Hardness	ISO 868	Shore D	≥85
Coefficient of Linear Thermal Expansion	ISO 11359-2	10-6/K	≤65
Long-term Service Temperature	UL 746B	℃	250
Heat Deflection Temperature	ISO 75-2	℃	≥150
WaterAbsorption (23℃、Water、24h)	ISO 62	%	≤0.1
Flammability Resistance (1.6mm)	UL94	/	V-0
Volume Resistivity	IEC 62631-3-1	Q ·cm	1014-1016
Dielectric Strength	IEC 60243-1	kV/mm	≥15
DielectricConstant(1MHz)	IEC 62631-2-1	/	3.4
Dielectric Loss(1MHz)	IEC 62631-2-1	/	0.086

PEEK GF30 Sheet Specification
Dimension Thickness*Width（mm）	Length(mm)	Weight(kg)
6 x 620	1000	7. 17
8 x 620	1000	9.56
10 x 620	1000	11.47
12 x 620	1000	13.38
15 x 620	1000	16.73
16 x 620	1000	18. 17
20 x 620	1000	21.99
25 x 620	1000	26.77
30 x 620	1000	31.55
40 x 620	1000	41. 11
50 x 620	1000	50.55

PEEK GF30 Sheet Specification
Dimension Thickness*Width（mm）	Length(mm)	Weight(kg)
6 x 620	1000	7. 17
8 x 620	1000	9.56
10 x 620	1000	11.47
12 x 620	1000	13.38
15 x 620	1000	16.73
16 x 620	1000	18. 17
20 x 620	1000	21.99
25 x 620	1000	26.77
30 x 620	1000	31.55
40 x 620	1000	41. 11
50 x 620	1000	50.55
