JUTAIPEEK®ESD-FC, PEEK ESD rod is a High Performance electrostatic-dissipative PEEK, with uniform, stable, and concentrated surface resistivity at 10^7-10^8Ω/sq or 10^8-10^9Ω/sq.
JUTAIPEEK®ESD-FC, the electrostatic dissipative grade, contains specific additives that enable it to perform exceptionally well in wear and friction applications where anti-static properties are crucial. As a result, this PEEK ESD rod excels in electronic fixture applications that require high dimensional stability over a wide thermal range and precise machinability. It is ideal for chip trays and carriers, PCB board manufacturing, and electronic component fixtures.
JUTAIPEEK®ESD-FC, PEEK ESD rod is a High Performance electrostatic-dissipative PEEK, with uniform, stable, and concentrated surface resistivity at 10^7-10^8Ω/sq or 10^8-10^9Ω/sq.
JUTAIPEEK®ESD-FC, the electrostatic dissipative grade, contains specific additives that enable it to perform exceptionally well in wear and friction applications where anti-static properties are crucial. As a result, this PEEK ESD rod excels in electronic fixture applications that require high dimensional stability over a wide thermal range and precise machinability. It is ideal for chip trays and carriers, PCB board manufacturing, and electronic component fixtures.
● Excellent sliding friction performance
● High dimensional stability
● Outstanding antistatic properties with a surface resistivity of 10^7-10^9 Ω/sq, providing uniform, stable, and consistent surface resistivity, and controlled within 2 orders of magnitude
● Suitable for complex structural components
● Excellent sliding friction performance
● High dimensional stability
● Outstanding antistatic properties with a surface resistivity of 10^7-10^9 Ω/sq, providing uniform, stable, and consistent surface resistivity, and controlled within 2 orders of magnitude
● Suitable for complex structural components
In Electronics and Semiconductor Industry, ESD PEEK is used to produce various products that provide electrostatic protection while ensuring mechanical strength, thermal stability, and chemical resistance. Common ESD PEEK products in this industry include:
1. ESD PEEK of Chip Trays
2. ESD PEEK Wafer Carrier
3. PCB Assembly Fixtures
4. Testing Sockets and IC Test Fixture
5. Pick-and-Place Nozzles and Machine Parts
6. Vacuum Chucks and Holders
7. Component Handling Tools
8. Electronic Enclosures and Housing
In Electronics and Semiconductor Industry, ESD PEEK is used to produce various products that provide electrostatic protection while ensuring mechanical strength, thermal stability, and chemical resistance. Common ESD PEEK products in this industry include:
1. ESD PEEK of Chip Trays
2. ESD PEEK Wafer Carrier
3. PCB Assembly Fixtures
4. Testing Sockets and IC Test Fixture
5. Pick-and-Place Nozzles and Machine Parts
6. Vacuum Chucks and Holders
7. Component Handling Tools
8. Electronic Enclosures and Housing
Performance | Test Method | Unit | PEEKESD-FC |
Color | Eye | / | Black |
Density | ISO1183-1 | g/cm3 | 1.35-1.36 |
Tensile Strength | ISO 527-2 | MPa | >100 |
Tensile Modulus | ISO 527-2 | GPa | >4.0 |
Izod Impact Strength | ISO 180 | kJ/m2 | >3.5 |
Flexural Strength | ISO178 | MPa | >150 |
Flexural Modulus | ISO178 | GPa | >4.5 |
Shore D Hardness | ISO 868 | Shore D | >80 |
Rockwell Hardness | ISO 2039-2 | M | >100 |
Melt Temperature | ISO11357-3 | ℃ | >334 |
Coefficient of Linear Thermal Expansion | ISO11359-2 | 10-6/K | ≤60 |
Long-term Service Temperature | UL746B | ℃ | 220-260 |
Heat Deflection Temperature | ISO75-2 | ℃ | >175 |
Water Absorption (23℃、water、24h) | ISO 62 | % | ≤0.1 |
Flame Retardancy | UL94 | / | V-0 |
Surface Resistivity | IEC61340-2-3 | Qsq | 10^7-10^8/10^8-10^9 |
Notes: Antistatic property is characterized by surface resistivity and the test methods are in accordance with IEC61340-2-3, and the testing electrode is Concentric Ring Electrode
Performance | Test Method | Unit | PEEKESD-FC |
Color | Eye | / | Black |
Density | ISO1183-1 | g/cm3 | 1.35-1.36 |
Tensile Strength | ISO 527-2 | MPa | >100 |
Tensile Modulus | ISO 527-2 | GPa | >4.0 |
Izod Impact Strength | ISO 180 | kJ/m2 | >3.5 |
Flexural Strength | ISO178 | MPa | >150 |
Flexural Modulus | ISO178 | GPa | >4.5 |
Shore D Hardness | ISO 868 | Shore D | >80 |
Rockwell Hardness | ISO 2039-2 | M | >100 |
Melt Temperature | ISO11357-3 | ℃ | >334 |
Coefficient of Linear Thermal Expansion | ISO11359-2 | 10-6/K | ≤60 |
Long-term Service Temperature | UL746B | ℃ | 220-260 |
Heat Deflection Temperature | ISO75-2 | ℃ | >175 |
Water Absorption (23℃、water、24h) | ISO 62 | % | ≤0.1 |
Flame Retardancy | UL94 | / | V-0 |
Surface Resistivity | IEC61340-2-3 | Qsq | 10^7-10^8/10^8-10^9 |
Notes: Antistatic property is characterized by surface resistivity and the test methods are in accordance with IEC61340-2-3, and the testing electrode is Concentric Ring Electrode
PEEKOESD-FC Rod Specification | |||||
Diameter xLength | Unit Weight | Diameter xLength | Unit Weight | Diameter xLength | Unit Weight |
10x1000 | 0.156 | 10x2000 | 0.312 | 10x3000 | 0.468 |
12x1000 | 0.21 | 12x2000 | 0.42 | 12x3000 | 0.63 |
15x1000 | 0.31 | 15x2000 | 0.62 | 15x3000 | 0.93 |
18x1000 | 0.43 | 18x2000 | 0.86 | 18x3000 | 1.29 |
20x1000 | 0.52 | 20x2000 | 1.04 | 20x3000 | 1.56 |
25x1000 | 0.79 | 25x2000 | 1.58 | 25x3000 | 2.37 |
28x1000 | 0.97 | 28x2000 | 1.94 | 28x3000 | 2.91 |
30x1000 | 1.11 | 30x2000 | 2.22 | 30x3000 | 3.33 |
35x1000 | 1.48 | 35x2000 | 2.96 | 35x3000 | 4.44 |
40x1000 | 1.91 | 40x2000 | 3.82 | 40x3000 | 5.73 |
50x1000 | 2.92 | 50x2000 | 5.84 | 50x3000 | 8.76 |
60x1000 | 4.15 | 60x2000 | 8.3 | 60x3000 | 12.45 |
PEEKOESD-FC Rod Specification | |||||
Diameter xLength | Unit Weight | Diameter xLength | Unit Weight | Diameter xLength | Unit Weight |
10x1000 | 0.156 | 10x2000 | 0.312 | 10x3000 | 0.468 |
12x1000 | 0.21 | 12x2000 | 0.42 | 12x3000 | 0.63 |
15x1000 | 0.31 | 15x2000 | 0.62 | 15x3000 | 0.93 |
18x1000 | 0.43 | 18x2000 | 0.86 | 18x3000 | 1.29 |
20x1000 | 0.52 | 20x2000 | 1.04 | 20x3000 | 1.56 |
25x1000 | 0.79 | 25x2000 | 1.58 | 25x3000 | 2.37 |
28x1000 | 0.97 | 28x2000 | 1.94 | 28x3000 | 2.91 |
30x1000 | 1.11 | 30x2000 | 2.22 | 30x3000 | 3.33 |
35x1000 | 1.48 | 35x2000 | 2.96 | 35x3000 | 4.44 |
40x1000 | 1.91 | 40x2000 | 3.82 | 40x3000 | 5.73 |
50x1000 | 2.92 | 50x2000 | 5.84 | 50x3000 | 8.76 |
60x1000 | 4.15 | 60x2000 | 8.3 | 60x3000 | 12.45 |
