JUTAIPEEK®WR01 ,wear-resistant polyetheretherketone rod, WR01 ROD has the lowest wear rate and highest PV rating among all ketone-based polymers. It is the original material for bearing-grade PEEK and remains the most sought-after material among bearing-grade 10-10-10 PEEK materials. PEEK 450FC30 contains 10% graphite, 10% carbon fiber, and 10% PTFE powder, and is unaffected by repeated high-pressure sterilization, making it an ideal choice for bushings and gears in reusable medical devices. PEEK 450FC30 meets FDA standards for direct food contact applications and complies with the most stringent flammability and low smoke generation requirements of the aerospace industry.
JUTAIPEEK®WR01 ,wear-resistant polyetheretherketone rod, WR01 ROD has the lowest wear rate and highest PV rating among all ketone-based polymers. It is the original material for bearing-grade PEEK and remains the most sought-after material among bearing-grade 10-10-10 PEEK materials. PEEK 450FC30 contains 10% graphite, 10% carbon fiber, and 10% PTFE powder, and is unaffected by repeated high-pressure sterilization, making it an ideal choice for bushings and gears in reusable medical devices. PEEK 450FC30 meets FDA standards for direct food contact applications and complies with the most stringent flammability and low smoke generation requirements of the aerospace industry.
Wear resistance PEEK Rods’ tribological applications for high strength. Excellent wear resistance, extremely low coefficient of friction, and low thermal expansion coefficient. Its strength, temperature resistance, and chemical resistance make it a candidate for dynamic applications that require long service life in harsh environments. In many applications, it can be used without external lubrication
● Bushings and bearings
● High-temperature wear pads
● Electrostatic dissipative components
● Valve seats, sealing surfaces
Wear resistance PEEK Rods’ tribological applications for high strength. Excellent wear resistance, extremely low coefficient of friction, and low thermal expansion coefficient. Its strength, temperature resistance, and chemical resistance make it a candidate for dynamic applications that require long service life in harsh environments. In many applications, it can be used without external lubrication
● Bushings and bearings
● High-temperature wear pads
● Electrostatic dissipative components
● Valve seats, sealing surfaces
Use a lathe or milling machine to remove the surface heat treatment aging layer, generally removing 0.5-1mm.
For milling, choose PCD-coated tools.
For drilling, use PCD-coated drill bits, and follow the principle of drilling a pilot hole before enlarging.
During processing, ensure sufficient coolant to prevent material burning or tool sticking.
It is recommended to use water-soluble cutting fluids.
Storage Instructions:
Keep away from light, moisture, and oily substances.
If not in use, wrap it properly with film.
Use a lathe or milling machine to remove the surface heat treatment aging layer, generally removing 0.5-1mm.
For milling, choose PCD-coated tools.
For drilling, use PCD-coated drill bits, and follow the principle of drilling a pilot hole before enlarging.
During processing, ensure sufficient coolant to prevent material burning or tool sticking.
It is recommended to use water-soluble cutting fluids.
Storage Instructions:
Keep away from light, moisture, and oily substances.
If not in use, wrap it properly with film.
Performance | Test Method | Unit | Wear Resistance PEEK |
Color | Eye | / | black |
Density | ISO 1183-1 | g/cm3 | 1.43 |
Tensile Strength | ISO 527-2 | MPa | ≥90 |
Tensile Modulus | ISO 527-2 | GPa | ≥6 |
Charpy Impact Strength(Notched) | ISO 179 | kJ/m2 | ≥4.0 |
Flexural Strength | ISO 178 | MPa | ≥140 |
Flexural Modulus | ISO 178 | GPa | ≥6 |
Rockwell Hardness | ISO 2039-2 | M | ≥100 |
Melt Temperature | ISO 11357-3 | ℃ | ≥334 |
Thermal Conductivity | ISO 8302 | W/(m-K) | 0.7-1.0 |
Coefficient of Linear Thermal Expansion | ISO 11359-2 | 10-6/K | ≤50 |
Long-term ServiceTemperature | UL 746B | ℃ | 240 |
Heat Deflection Temperature | ISO 75-2 | ℃ | ≥260 |
Water Absorption(23℃,water,24h) | ISO 62 Method 1 | % | ≤0.10 |
Volume Resistivity | IEC62631-3-1 | Q ·cm | ≤10^11 |
Flame Retardancy | UL 94 | / | V-0 |
Frictional Coefficient | ASTM D3702 | / | 0.15±0.05 |
Wear Rate | um/h | 4.2±0.8 |
Performance | Test Method | Unit | Wear Resistance PEEK |
Color | Eye | / | black |
Density | ISO 1183-1 | g/cm3 | 1.43 |
Tensile Strength | ISO 527-2 | MPa | ≥90 |
Tensile Modulus | ISO 527-2 | GPa | ≥6 |
Charpy Impact Strength(Notched) | ISO 179 | kJ/m2 | ≥4.0 |
Flexural Strength | ISO 178 | MPa | ≥140 |
Flexural Modulus | ISO 178 | GPa | ≥6 |
Rockwell Hardness | ISO 2039-2 | M | ≥100 |
Melt Temperature | ISO 11357-3 | ℃ | ≥334 |
Thermal Conductivity | ISO 8302 | W/(m-K) | 0.7-1.0 |
Coefficient of Linear Thermal Expansion | ISO 11359-2 | 10-6/K | ≤50 |
Long-term ServiceTemperature | UL 746B | ℃ | 240 |
Heat Deflection Temperature | ISO 75-2 | ℃ | ≥260 |
Water Absorption(23℃,water,24h) | ISO 62 Method 1 | % | ≤0.10 |
Volume Resistivity | IEC62631-3-1 | Q ·cm | ≤10^11 |
Flame Retardancy | UL 94 | / | V-0 |
Frictional Coefficient | ASTM D3702 | / | 0.15±0.05 |
Wear Rate | um/h | 4.2±0.8 |
PEEKWR01 Rod Specification | |||||
Diameter x Length | Unit Weight | Diameter x Length | Unit Weight | Diameter x Length | Unit Weight |
10 x 1000 | 0.16 | 10 x 2000 | 0.33 | 10 x 3000 | 0.49 |
12 x 1000 | 0.22 | 12 x 2000 | 0.44 | 12 x 3000 | 0.66 |
15 x 1000 | 0.33 | 15 x 2000 | 0.65 | 15 x 3000 | 0.98 |
18x 1000 | 0.56 | 18 x 2000 | 1.11 | 18 x 3000 | 1.67 |
20 x 1000 | 0.84 | 20 x 2000 | 1.67 | 20 x 3000 | 2.51 |
25 x 1000 | 1.25 | 25 x 2000 | 2.50 | 25 x 3000 | 3.75 |
28 x 1000 | 1.65 | 28 x 2000 | 3.30 | 28 x 3000 | 4.95 |
30 x 1000 | 2.11 | 30 x 2000 | 4.23 | 30 x 3000 | 6.34 |
35 x 1000 | 3.22 | 35 x 2000 | 6.43 | 35 x 3000 | 9.65 |
40 x 1000 | 4.54 | 40 x 2000 | 9.08 | 40 x 3000 | 13.63 |
50 x 1000 | 6.10 | 50 x 2000 | 12.20 | 50 x 3000 | 18.29 |
60 x 1000 | 8.08 | 60 x 2000 | 16.15 | 60 x 3000 | 24.23 |
PEEKWR01 Rod Specification | |||||
Diameter x Length | Unit Weight | Diameter x Length | Unit Weight | Diameter x Length | Unit Weight |
10 x 1000 | 0.16 | 10 x 2000 | 0.33 | 10 x 3000 | 0.49 |
12 x 1000 | 0.22 | 12 x 2000 | 0.44 | 12 x 3000 | 0.66 |
15 x 1000 | 0.33 | 15 x 2000 | 0.65 | 15 x 3000 | 0.98 |
18x 1000 | 0.56 | 18 x 2000 | 1.11 | 18 x 3000 | 1.67 |
20 x 1000 | 0.84 | 20 x 2000 | 1.67 | 20 x 3000 | 2.51 |
25 x 1000 | 1.25 | 25 x 2000 | 2.50 | 25 x 3000 | 3.75 |
28 x 1000 | 1.65 | 28 x 2000 | 3.30 | 28 x 3000 | 4.95 |
30 x 1000 | 2.11 | 30 x 2000 | 4.23 | 30 x 3000 | 6.34 |
35 x 1000 | 3.22 | 35 x 2000 | 6.43 | 35 x 3000 | 9.65 |
40 x 1000 | 4.54 | 40 x 2000 | 9.08 | 40 x 3000 | 13.63 |
50 x 1000 | 6.10 | 50 x 2000 | 12.20 | 50 x 3000 | 18.29 |
60 x 1000 | 8.08 | 60 x 2000 | 16.15 | 60 x 3000 | 24.23 |
